Cisco Catalyst 9200L-24P-4G 24-Port PoE+ Switch, 4×1G Uplinks, Network Essentials & Advantage
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Cisco Catalyst C9200L-24P-4G Series Switches
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
Quick Buying Guide: Essentials vs. Advantage
Engineer's Choice:
-
Network Essentials: Best for standard Layer 2 access with basic Layer 3 routing (Static, RIP, OSPF). Cost-effective for branch offices and general campus access deployments.
-
Network Advantage: Unlocks full Layer 3 routing (BGP, EIGRP, ISIS), advanced policy-based segmentation, and full DNA Center features. Ideal for SD-Access, high-security enterprise cores, and mission-critical networks.
Tip: If your deployment requires SD-Access, dynamic segmentation, or advanced Layer 3 routing, Advantage is the recommended edition. Essentials is sufficient for most access-layer and branch scenarios.
Overview
The Cisco Catalyst 9200L-24P-4G is a compact, high-performance PoE+ switch designed for enterprise and branch networks. With 24 PoE+ ports and 4×1G uplinks, it ensures reliable connectivity for wireless APs, IP cameras, IoT devices, and general office endpoints.
Built on Catalyst 9000 hardware and Cisco IOS XE software, it combines high security, simplified automation via Cisco DNA Center, and resilient architecture with field-replaceable power and fans. Whether choosing Essentials or Advantage, it delivers enterprise-grade performance with plug-and-play simplicity, stacking up to 80 Gbps.
Highlights:
-
24 Gigabit PoE+ ports, 370W total PoE budget
-
4×1G fixed uplinks; optional stacking with 80 Gbps throughput
-
Layer 3 routing: Static, RIP, OSPF, EIGRP, BGP, ISIS (Advantage only)
-
Cisco SD-Access-ready for automated policy deployment
-
AES-128 MACsec encryption & policy-based segmentation
-
UADP 2.0 Mini ASIC for optimized performance and scale
-
Flexible NetFlow for detailed traffic monitoring
-
Plug-and-Play (PnP) for rapid branch deployment
-
Jumbo frame support up to 9,198 bytes
-
Cisco DNA Center integration for network assurance
Technical Insight from our CCIE Engineers:
When deploying high-end Wi-Fi 7 APs or IP cameras, ensure the PoE budget accommodates 370W. For stacking, the C9200L-STACK-KIT is required. Complimentary pre-configuration scripts are available from our certified engineers.
Comparison with Same Series
| Feature | C9200 | C9200L | C9200CX | Why It Matters |
|---|---|---|---|---|
| Stacking bandwidth | 160 Gbps | 80 Gbps | N/A | C9200L offers sufficient 80Gbps stacking for cost-effective projects without modular uplinks. |
| Total MAC addresses | 32,000 | 16,000 | 32,000 | Supports large endpoint counts in small-to-mid deployments. |
| IPv4 routes | 14,000 | 11,000 | 14,000 | Adequate routing scale for typical campus/branch networks. |
| DRAM | 4 GB | 2 GB | 4 GB | Memory sufficient for Essentials/Advantage workloads. |
| ACL entries | 1,600 | 1,500 | 1,600 | Maintains security policies without performance degradation. |
| Flexible NetFlow | 16,000 | 16,000 | 16,000 | Real-time traffic monitoring at scale. |
Why choose C9200L over C9200?
The C9200L is optimized for budget-conscious deployments requiring enterprise-grade security, reliable PoE+, and simplified 80Gbps stacking, while maintaining full compatibility with Catalyst 9000 features.
Specifications: Cisco C9200L-24P-4G
Performance & Network Scale:
| Specification | Value |
|---|---|
| Virtual Networks | 1 |
| Stacking bandwidth | 80 Gbps |
| Total MAC addresses | 16,000 |
| IPv4 routes (ARP + learned) | 11,000 |
| IPv4 routing entries | 3,000 |
| IPv6 routing entries | 1,500 |
| Multicast routing scale | 1,000 |
| QoS scale entries | 1,000 |
| ACL scale entries | 1,500 |
| Packet buffer | 6 MB |
| Flexible NetFlow entries | 16,000 |
| DRAM | 2 GB |
| Flash | 4 GB |
| VLAN IDs | 4,094 |
| PVST Instances | 128 |
| STP Virtual Ports PVST | 13,000 |
| STP Virtual Ports MST | 13,000 |
| Total SVIs | 512 |
| Jumbo Frames | 9,198 bytes |
| Wireless bandwidth | N/A |
| IP SGT binding scale | 10,000 |
| IPv4 bindings | 10,000 |
| SGT/DGT policies | 2,000 |
| SXP Sessions | 200 |
| Compatibility Note | Fully compatible with NS-branded high-compatibility optical modules for cost-saving fiber deployments |
Bandwidth Specifications:
| Metric | Value |
|---|---|
| Switching capacity | 56 Gbps |
| Switching capacity with stacking | 136 Gbps |
| Forwarding rate | 41.67 Mpps |
| Forwarding rate with stacking | 101 Mpps |
Common SKU Versions:
-
C9200L-24P-4G-E (Network Essentials)
-
C9200L-24P-4G-A (Network Advantage)
Use Cases & Deployment Scenarios:
-
Campus Access Layer: Support high-density wired and wireless endpoints
-
Branch Offices: Cost-effective, secure, and easy-to-deploy access layer
-
Wi-Fi AP Integration: Full PoE+ support for modern APs
-
IP Camera & Surveillance: Reliable PoE for security systems
-
IoT Devices & Smart Office: Connect sensors, badge readers, smart devices
-
Stacked Access Closets: Simplify management and scale port density seamlessly
-
Policy Automation & SD-Access: Automated segmentation and provisioning
-
Network Monitoring & Assurance: Real-time analytics via Cisco DNA Center
