AXIS I5304 Network Answering Unit Black (03239-001)
Clique ou role para ampliar
Toque ou belisque para ampliar
AXIS I5304 Network Answering Unit Black (03239-001)
AXIS I5304 Network Answering Unit Black (03239-001)

AXIS I5304 Network Answering Unit Black (03239-001)

por Axis
R$ 10.044,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc] 7" touch display, SIP support, PoE powered, two-way audio, HD video, desk or wall mount (requires accessory). [/shortdesc]

[properties]

Model AXIS I5304 Black (03239-001)
Product Type Network Answering Unit
Color Black RAL 9005
Display Size 7” LCD
Display Resolution 1024 × 600
Control Technology Capacitive Touch Panel
Audio Hardware Two-way full duplex; Built-in microphone; Built-in speaker 84 dBC @ 1m; Line-out 600 mV RMS
Video Support Up to 1280×720, 30 fps (H.264, MJPEG)
Network Protocols IPv4, HTTP, HTTPS, SIP 2.0, SIPS, TLS, RTP, SRTP, RTSP, DHCP, NTP, TCP, IGMP, UDP, DNS, Syslog, FTP, SMTP, RTCP, ICMP, DHCPv4
VoIP Compatibility SIP/PBX, Peer-to-Peer; DTMF (audio, RFC2833, RFC2976)
Power PoE IEEE 802.3af Class 3 (2.9 W typ, 12 W max); 12 VDC, 1 A
Connectors RJ45 10/100 PoE; Doorbell input (NO contact)
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature −20 °C to 70 °C (−4 °F to 158 °F)
Operating Humidity 10–90% RH (non-condensing)
Altitude 0 to 2000 m (0 to 6500 ft)
Casing Tempered glass surface; Plastic body
Dimensions See datasheet diagrams
Weight 555 g (1.2 lb)

[/properties]

[specifications]

Operating System Powered by 2N OS
Display Features Touch control; Visual verification; Incoming/outgoing calling; HTTP command support; Unlock doors
Audio Encoding G.711, G.722, G.729, L16/16 kHz
Video Compression H.264 (MPEG-4 Part 10/AVC), Motion JPEG
Cybersecurity IEEE 802.1X, HTTPS, TLS v1.2, X.509 Certificate PKI
Certifications CSA, UL/cUL, CE, VCCI, RCM
EMC Compliance EN 55035, EN 55032 Class B, FCC Part 15 Class B, ICES(B)/NMB(B)
Safety Compliance CAN/CSA C22.2 No. 62368-1 ed. 3; IEC/EN/UL 62368-1 ed. 3
Sustainability PVC/BFR/CFR-free; RoHS compliant; REACH compliant; Conflict-minerals screened
Languages English, German, French, Spanish, Italian, Japanese, Dutch, Czech

[/specifications]

[accesories]

Included in the Box Answering unit; Installation guide; Certificate of ownership; 2.5 mm hex key wrench; Terminal block connectors (power & doorbell)
Optional Mounts (Required) AXIS T15201 Recessed Mount; AXIS T15601 Wall Mount; AXIS T15602 Desk Stand

[/accesories]

The AXIS I5304 Network Answering Unit (Black) delivers secure, high-quality communication for professional environments that rely on reliable access control. Featuring a responsive 7-inch capacitive touchscreen, the unit enables receptionists, concierges, and security staff to easily verify visitors through live video and two-way audio. With built-in SIP support and PoE power, it streamlines deployment and ensures seamless integration with IP intercom and VoIP systems.

  • 7" Capacitive Touch Display: Provides a sharp 1024×600 interface for smooth call handling and visual verification.
  • Two-Way Full Duplex Audio: Built-in microphone and speaker deliver clear communication with echo cancellation, powered by high-quality G.711/G.722 codecs.
  • HD Video Support: Displays H.264 or Motion JPEG feeds up to 1280×720 at 30 fps for secure monitoring.
  • SIP & VoIP Integration: Fully supports SIP 2.0 and PBX environments for flexible voice system compatibility.
  • Flexible Installation: Supports Power over Ethernet (PoE IEEE 802.3af) for single-cable connectivity. Note: A mounting accessory (Desk, Wall, or Recessed) is required for installation.
  • Office building receptions requiring visual visitor verification
  • Commercial facilities with multi-tenant access systems
  • Hospitality and concierge desks handling frequent guest calls
  • Security control rooms needing reliable SIP-based communication
  • Any environment using IP intercoms with door unlocking capability
  • Display: 7" color LCD, 1024×600 resolution
  • Touch Panel: Capacitive multi-touch
  • Video Support: H.264, Motion JPEG up to 1280×720 at 30 fps
  • Audio: Full duplex, built-in microphone and speaker, 84 dBC output
  • Network Protocols: IPv4, HTTP/HTTPS, SIP/SIPS, RTP/SRTP, RTSP, DHCP, TCP, UDP, DNS
  • Security: HTTPS, TLS v1.2, IEEE 802.1X, X.509 certificate support
  • Power: PoE IEEE 802.3af Class 3 or 12V DC input
  • Connectivity: RJ45 10/100 Ethernet, doorbell input, line-out for hearing loop
  • Operating Conditions: 0 °C to 50 °C; 10–90% RH non-condensing
  • Mounting Options: Desk stand (T15602), wall mount (T15601), or recessed mount (T15201) — sold separately

Enhance your access control with reliable communication, cybersecurity features, and seamless system integration. Order the AXIS I5304 today for superior premise security.

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc] 7" touch display, SIP support, PoE powered, two-way audio, HD video, desk or wall mount (requires accessory). [/shortdesc]

[properties]

Model AXIS I5304 Black (03239-001)
Product Type Network Answering Unit
Color Black RAL 9005
Display Size 7” LCD
Display Resolution 1024 × 600
Control Technology Capacitive Touch Panel
Audio Hardware Two-way full duplex; Built-in microphone; Built-in speaker 84 dBC @ 1m; Line-out 600 mV RMS
Video Support Up to 1280×720, 30 fps (H.264, MJPEG)
Network Protocols IPv4, HTTP, HTTPS, SIP 2.0, SIPS, TLS, RTP, SRTP, RTSP, DHCP, NTP, TCP, IGMP, UDP, DNS, Syslog, FTP, SMTP, RTCP, ICMP, DHCPv4
VoIP Compatibility SIP/PBX, Peer-to-Peer; DTMF (audio, RFC2833, RFC2976)
Power PoE IEEE 802.3af Class 3 (2.9 W typ, 12 W max); 12 VDC, 1 A
Connectors RJ45 10/100 PoE; Doorbell input (NO contact)
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature −20 °C to 70 °C (−4 °F to 158 °F)
Operating Humidity 10–90% RH (non-condensing)
Altitude 0 to 2000 m (0 to 6500 ft)
Casing Tempered glass surface; Plastic body
Dimensions See datasheet diagrams
Weight 555 g (1.2 lb)

[/properties]

[specifications]

Operating System Powered by 2N OS
Display Features Touch control; Visual verification; Incoming/outgoing calling; HTTP command support; Unlock doors
Audio Encoding G.711, G.722, G.729, L16/16 kHz
Video Compression H.264 (MPEG-4 Part 10/AVC), Motion JPEG
Cybersecurity IEEE 802.1X, HTTPS, TLS v1.2, X.509 Certificate PKI
Certifications CSA, UL/cUL, CE, VCCI, RCM
EMC Compliance EN 55035, EN 55032 Class B, FCC Part 15 Class B, ICES(B)/NMB(B)
Safety Compliance CAN/CSA C22.2 No. 62368-1 ed. 3; IEC/EN/UL 62368-1 ed. 3
Sustainability PVC/BFR/CFR-free; RoHS compliant; REACH compliant; Conflict-minerals screened
Languages English, German, French, Spanish, Italian, Japanese, Dutch, Czech

[/specifications]

[accesories]

Included in the Box Answering unit; Installation guide; Certificate of ownership; 2.5 mm hex key wrench; Terminal block connectors (power & doorbell)
Optional Mounts (Required) AXIS T15201 Recessed Mount; AXIS T15601 Wall Mount; AXIS T15602 Desk Stand

[/accesories]

Enhance Visitor Communication with Intelligent Touch Control

The AXIS I5304 Network Answering Unit (Black) delivers secure, high-quality communication for professional environments that rely on reliable access control. Featuring a responsive 7-inch capacitive touchscreen, the unit enables receptionists, concierges, and security staff to easily verify visitors through live video and two-way audio. With built-in SIP support and PoE power, it streamlines deployment and ensures seamless integration with IP intercom and VoIP systems.

Key Benefits & Features
  • 7" Capacitive Touch Display: Provides a sharp 1024×600 interface for smooth call handling and visual verification.
  • Two-Way Full Duplex Audio: Built-in microphone and speaker deliver clear communication with echo cancellation, powered by high-quality G.711/G.722 codecs.
  • HD Video Support: Displays H.264 or Motion JPEG feeds up to 1280×720 at 30 fps for secure monitoring.
  • SIP & VoIP Integration: Fully supports SIP 2.0 and PBX environments for flexible voice system compatibility.
  • Flexible Installation: Supports Power over Ethernet (PoE IEEE 802.3af) for single-cable connectivity. Note: A mounting accessory (Desk, Wall, or Recessed) is required for installation.
Ideal Use Cases
  • Office building receptions requiring visual visitor verification
  • Commercial facilities with multi-tenant access systems
  • Hospitality and concierge desks handling frequent guest calls
  • Security control rooms needing reliable SIP-based communication
  • Any environment using IP intercoms with door unlocking capability
Technical Specifications
  • Display: 7" color LCD, 1024×600 resolution
  • Touch Panel: Capacitive multi-touch
  • Video Support: H.264, Motion JPEG up to 1280×720 at 30 fps
  • Audio: Full duplex, built-in microphone and speaker, 84 dBC output
  • Network Protocols: IPv4, HTTP/HTTPS, SIP/SIPS, RTP/SRTP, RTSP, DHCP, TCP, UDP, DNS
  • Security: HTTPS, TLS v1.2, IEEE 802.1X, X.509 certificate support
  • Power: PoE IEEE 802.3af Class 3 or 12V DC input
  • Connectivity: RJ45 10/100 Ethernet, doorbell input, line-out for hearing loop
  • Operating Conditions: 0 °C to 50 °C; 10–90% RH non-condensing
  • Mounting Options: Desk stand (T15602), wall mount (T15601), or recessed mount (T15201) — sold separately
Upgrade to a Smarter Visitor Management Workflow

Enhance your access control with reliable communication, cybersecurity features, and seamless system integration. Order the AXIS I5304 today for superior premise security.
