AXIS A9801 Security Relay (5801-141)
AXIS A9801 Security Relay (5801-141)

AXIS A9801 Security Relay (5801-141)

por Axis
R$ 1.824,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc]

  • Automatically cuts connection to the door strike, Doubles the 12 V output, allowing control of 24 V locks without extra wiring or power supply.


[/shortdesc]

[properties]

Product Name AXIS A9801 Security Relay (5801-141)
Description Compact relay designed for integration with Axis network video door stations to enhance door security and prevent unauthorized access during tampering.
Tamper Response Automatically disconnects door strike upon tampering, keeping the door locked.
Input Voltage Range Operates between 11 V and 13 V
Output Voltage Options Provides either 12 V (730 mA) or boosted 24 V (300 mA) for flexible door strike support
Voltage Doubling Doubles input from 12 V to 24 V, allowing for control of higher voltage door strikes without extra wiring
Dimensions 48 x 45 x 30 mm (1.9 x 1.8 x 1.2 in), fits standard installation boxes (US Single Gang, EU 60mm)
Weight 100 g (0.2 lbs), lightweight for easy installation
Reset Mechanism Equipped with a reset button to manually restore function post-tampering
Compatible Door Strikes Supports both 12 V and 24 V door strikes, offering flexibility in various applications
Installation Suitable for installation within standard indoor electrical boxes, enabling easy integration
Temperature Range Designed for environments between -20 °C and 50 °C (-4 °F to 122 °F)
Humidity Range Operates reliably in humidity from 10-100% (condensing)
Material Constructed with flame-retardant plastic casing to minimize risk and enhance safety
Power Efficiency Low power consumption, with max 8.76 W under full operation

[/properties]

[specifications]

Environment Indoor
Input 11–13 V DC, max 750 mA
Relay Input Max 30 V DC, 1.2 A
Output 12 V (730 mA) or 24 V (300 mA)
Mounting Shelf mount; fits US Single Gang or EU 60 mm boxes
Operating Conditions –20 °C to 50 °C (–4 °F to 122 °F), 10–100% RH (condensing)
Approvals EN 55022 Class A, EN 55024, EN 61000-6-1, EN 61000-6-2, AS/NZS CISPR 22 Class A, FCC Part 15 Class A, UL 60950-1, UL294
Dimensions 48 × 45 × 30 mm (1.9 × 1.8 × 1.2 in)
Weight 100 g (0.2 lb)

[/specifications]

AXIS A9801 Security Relay (5801-141)

The AXIS A9801 Security Relay is designed to improve security for doors controlled by Axis network video door stations. This compact relay, which fits in most standard installation boxes, is installed on the secure side of the door. In case of tampering or vandalism attempts, the relay cuts the connection to the door strike, ensuring that the door remains securely locked. The relay also acts as a power transformer, doubling the 12 V output from a door station to enable control of 24 V locks without the need for additional wiring or power supplies. The normal function can be restored via the relay's reset button.

  • Enhanced Security: Automatically cuts connection to the door strike in case of tampering, ensuring the door remains locked.
  • Supports Multiple Door Strikes: Compatible with both 12 V and 24 V door strikes for added flexibility.
  • Compact Design: Fits easily into standard installation boxes (US Single Gang, EU 60mm).
  • Power Transformer: Doubles the 12 V output, allowing control of 24 V locks without extra wiring or power supply.
  • Easy Installation: Pre-configured for simple installation with Axis door stations.
  • Environment: Indoor
  • Input: On +/-: min 11 V, max 13 V, max 750 mA; On relay: max 30 V DC, max 1.2 A
  • Output: 12 V (730 mA), 24 V (300 mA)
  • Mounting: Shelf mount; fits in standard installation boxes (US Single Gang, EU 60mm)
  • Operating Conditions: -20 °C to 50 °C (-4 °F to 122 °F), 10-100% humidity (condensing)
  • Certifications: EN 55022 Class A, EN 55024, EN 61000-6-1, FCC Part 15 Class A, UL 60950-1, UL294
  • Dimensions: 48 x 45 x 30 mm (1.9 x 1.8 x 1.2 in)
  • Weight: 100 g (0.2 lbs)


Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc]

  • Automatically cuts connection to the door strike, Doubles the 12 V output, allowing control of 24 V locks without extra wiring or power supply.


[/shortdesc]

[properties]

Product Name AXIS A9801 Security Relay (5801-141)
Description Compact relay designed for integration with Axis network video door stations to enhance door security and prevent unauthorized access during tampering.
Tamper Response Automatically disconnects door strike upon tampering, keeping the door locked.
Input Voltage Range Operates between 11 V and 13 V
Output Voltage Options Provides either 12 V (730 mA) or boosted 24 V (300 mA) for flexible door strike support
Voltage Doubling Doubles input from 12 V to 24 V, allowing for control of higher voltage door strikes without extra wiring
Dimensions 48 x 45 x 30 mm (1.9 x 1.8 x 1.2 in), fits standard installation boxes (US Single Gang, EU 60mm)
Weight 100 g (0.2 lbs), lightweight for easy installation
Reset Mechanism Equipped with a reset button to manually restore function post-tampering
Compatible Door Strikes Supports both 12 V and 24 V door strikes, offering flexibility in various applications
Installation Suitable for installation within standard indoor electrical boxes, enabling easy integration
Temperature Range Designed for environments between -20 °C and 50 °C (-4 °F to 122 °F)
Humidity Range Operates reliably in humidity from 10-100% (condensing)
Material Constructed with flame-retardant plastic casing to minimize risk and enhance safety
Power Efficiency Low power consumption, with max 8.76 W under full operation

[/properties]

[specifications]

Environment Indoor
Input 11–13 V DC, max 750 mA
Relay Input Max 30 V DC, 1.2 A
Output 12 V (730 mA) or 24 V (300 mA)
Mounting Shelf mount; fits US Single Gang or EU 60 mm boxes
Operating Conditions –20 °C to 50 °C (–4 °F to 122 °F), 10–100% RH (condensing)
Approvals EN 55022 Class A, EN 55024, EN 61000-6-1, EN 61000-6-2, AS/NZS CISPR 22 Class A, FCC Part 15 Class A, UL 60950-1, UL294
Dimensions 48 × 45 × 30 mm (1.9 × 1.8 × 1.2 in)
Weight 100 g (0.2 lb)

[/specifications]

AXIS A9801 Security Relay (5801-141)

The AXIS A9801 Security Relay is designed to improve security for doors controlled by Axis network video door stations. This compact relay, which fits in most standard installation boxes, is installed on the secure side of the door. In case of tampering or vandalism attempts, the relay cuts the connection to the door strike, ensuring that the door remains securely locked. The relay also acts as a power transformer, doubling the 12 V output from a door station to enable control of 24 V locks without the need for additional wiring or power supplies. The normal function can be restored via the relay's reset button.

Key Features:
  • Enhanced Security: Automatically cuts connection to the door strike in case of tampering, ensuring the door remains locked.
  • Supports Multiple Door Strikes: Compatible with both 12 V and 24 V door strikes for added flexibility.
  • Compact Design: Fits easily into standard installation boxes (US Single Gang, EU 60mm).
  • Power Transformer: Doubles the 12 V output, allowing control of 24 V locks without extra wiring or power supply.
  • Easy Installation: Pre-configured for simple installation with Axis door stations.
Technical Specifications:
  • Environment: Indoor
  • Input: On +/-: min 11 V, max 13 V, max 750 mA; On relay: max 30 V DC, max 1.2 A
  • Output: 12 V (730 mA), 24 V (300 mA)
  • Mounting: Shelf mount; fits in standard installation boxes (US Single Gang, EU 60mm)
  • Operating Conditions: -20 °C to 50 °C (-4 °F to 122 °F), 10-100% humidity (condensing)
  • Certifications: EN 55022 Class A, EN 55024, EN 61000-6-1, FCC Part 15 Class A, UL 60950-1, UL294
  • Dimensions: 48 x 45 x 30 mm (1.9 x 1.8 x 1.2 in)
  • Weight: 100 g (0.2 lbs)
