Rack-Mountable 1U4L2E-B650 Server – Pre-Configured and Ready for Deployment
This high-performance 1U virtualization rack-mountable server is pre-configured and optimized for demanding workloads. Designed with cutting-edge components, it offers robust processing power, ample memory, and reliable storage to meet your business or data center needs.
Included components in the server:
Component |
Description |
Processor |
(6-core) processor with a base clock speed of 3.50 GHz and a maximum overclocking speed of 5.0 GHz. It features 12 threads, a 16MB L3 cache, and a 6MB L2 cache, built on a 4nm architecture. Designed for Socket AM5, this 64-bit processor includes integrated AMD Radeon 740M graphics and has a power rating of 65W.
|
Memory |
high-performance memory module featuring a 4800 MHz speed, ECC (Error-Correcting Code) for improved reliability, and a 1Rx8 configuration.
|
Primary Storage |
A 480GB SSD ensures ultra-fast read/write speeds and reliable data access.
|
Why Choose This Server?
This server is ideal for virtualization, database management, AI workloads, or file storage. Pre-configured and rigorously tested, it is ready to deploy upon arrival, saving you time and effort.
Upgrade your IT infrastructure with this reliable and versatile server. Buy with confidence and experience top-notch performance and scalability.
Customizable Server Solutions
We specialize in custom server builds tailored to your requirements. From component integration to full assembly and comprehensive burn-in testing, we ensure reliability and top-tier performance for your needs.
Key Specifications
Component |
Description |
Form Factor |
1U Rackmount |
Supported CPUs |
AMD EPYC™ 4004 and AMD Ryzen™ 9000/8000/7000 Series |
DIMM Slots |
4 DIMM slots (2DPC) |
Chipset |
AMD B650 |
BMC Controller |
ASPEED AST2600 |
Controller |
ASPEED AST2600: 1 x DB15 (VGA), 1 x (15-pin) header
AMD Processors with Graphics: 1 x HDMI, 1 x DisplayPort |
I/O Ports |
2 x Type-A (USB 3.2 Gen1)
2 x RJ45 (1GbE), 1 x dedicated IPMI
4 x Type-A (USB3.2 Gen1)
1 x DB9 (COM)
1 x DB15 (VGA), 1 x DisplayPort, 1 x HDMI
|
Supported Motherboard |
B650D4U |
Dimensions |
676.5 x 438 x 43.4 mm (26.6'' x 17.2'' x 1.7'') |
This server is a perfect fit for enterprise applications, virtualization, or high-performance computing. With its scalable features and robust build, it's ready to tackle the most demanding workloads
Compatible CPU |
AMD Ryzen™ 5 7600 6-Core 3.8 - 5.1GHz Turbo, AM5, 65W TDP, OEM Processor |
AMD Ryzen™ 7 7700 8-Core 3.8 - 5.3GHz Turbo, AM5, 65W TDP, OEM Processor |
AMD Ryzen™ 7 7700X 8-Core 4.5 - 5.4GHz Turbo, AM5, 105W TDP, OEM Processor |
AMD Ryzen™ 9 7900X 12-Core 4.7 - 5.6GHz Turbo, AM5, 170W TDP, OEM Processor |
AMD Ryzen™ 9 7950X 16-Core 4.5 - 5.7GHz Turbo, AM5, 170W TDP, OEM Processor |
AMD EPYC™ 4484PX 12-Core 4.4 - 5.6GHz Turbo, AM5, 120W TDP, OEM Processor |
AMD EPYC™ 4584PX 16-Core 4.2 - 5.7GHz Turbo, AM5, 120W TDP, OEM Processor |
AMD EPYC™ 4564P 16-Core 4.5 - 5.7GHz Turbo, AM5, 170W TDP, OEM Processor |
Compatible RAM |
4800MHz ECC Registered DDR5 DIMMs |
16GB PC5-38400 4800MHz DDR5 ECC RDIMM |
32GB PC5-38400 4800MHz DDR5 ECC RDIMM |
64GB PC5-38400 4800MHz DDR5 ECC RDIMM |
128GB PC5-38400 4800MHz DDR5 ECC RDIMM |
Compatible SSD |
480GB – 3.84TB Micron 7450 PRO Series M.2 PCIe 4.0 x4 NVMe Solid State Drive (80mm) |
960GB – 3.84TB Samsung PM9A3 Series M.2 PCIe 4.0 x4 NVMe Solid State Drive |
3.84TB – 30.72TB Solidigm SSD D7-P5520 Series U.2 PCIe 4.0 x4 NVMe Solid State Drive |
1.92TB – 30.72TB Micron 7450 PRO Series U.3 PCIe 4.0 x4 NVMe Solid State Drive (15mm) |
1.92TB – 15.0TB Samsung PM9A3 Series U.2 PCIe 4.0 x4 NVMe Solid State Drive (7mm) |
Compatible Network Cards |
Broadcom BCM5719-4P, 1Gbps, 4xRJ45, PCIe Network Adapter |
INTEL X550-T2, 10Gbps, 2xRJ45, PCIe Network Adapter |
INTEL I350T4V2BLK, 1Gbps, 4xRJ45, PCIe Network Adapter |
Broadcom BCM957416A4160C, 10Gbps, 2xRJ45, PCIe Network Adapter |
INTEL XXV710-DA2, 25Gbps, 2xSFP28, PCIe Network Adapter |
INTEL E810CQDA1, 100Gbps, 1xQSFP28, PCIe Network Adapter |
INTEL E810XXVDA4, 25Gbps, 4xSFP28, PCIe Network Adapter |
NVIDIA MCX623106AN-CDAT, 100Gbps, 2xQSFP56, PCIe Network Adapter |
NVIDIA MCX623105AN-VDAT, 200Gbps, QSFP56, PCIe Network Adapter |
Compatible Operating System |
Microsoft Windows Server 2022 |
Rocky Linux |
Ubuntu Linux |
Red Hat Enterprise Linux |
Boost your enterprise performance with the ASRock Customizable Server 1U4L2E-B650 6-Core AMD Ryzen 16GB DDR5 480GB SSD—ORDER TODAY!
