APC SRT5KRMXLTUS - Smart-UPS On-Line 5kVA 3U Rackmount UPS
Clique ou role para ampliar
Toque ou belisque para ampliar
APC SRT5KRMXLTUS - Smart-UPS On-Line 5kVA 3U Rackmount UPS
Clique ou role para ampliar
Toque ou belisque para ampliar
APC SRT5KRMXLTUS - Smart-UPS On-Line 5kVA 3U Rackmount UPS
APC SRT5KRMXLTUS - Smart-UPS On-Line 5kVA 3U Rackmount UPS

APC SRT5KRMXLTUS - Smart-UPS On-Line 5kVA 3U Rackmount UPS

por APC
Desconto de 33%
R$ 141.540,00
R$ 94.668,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc]

5400 VA / 4800 W, Double Conversion Online, 2x NEMA L6-20R + 2x NEMA L6-30R, Pre-installed Network Management Card 3

[/shortdesc]

[properties]

Brand APC by Schneider Electric
Model SRT5KRMXLTUS
Product Type Smart-UPS On-Line, Double Conversion
Form Factor Rackmount 3U
Dimensions (H x W x D) 5.1" x 17.0" x 28.3" (130 x 432 x 719 mm)
Weight 123 lb (55.79 kg)
Color Black
Number of Rack Units 3U
Cable Length 10 ft (3.05 m)
Cooling Not specified
[/properties]

[specifications]

Capacity 5400 VA / 4800 W
Input Voltage 208 V (other: 240 V) • Adjustable (half load): 100–275 V
Input Connection Type NEMA L6-30P
Input Frequency 40–70 Hz auto-sensing
Output Voltage 208 V (other: 240 V)
Output Connections 2 × NEMA L6-20R, 2 × NEMA L6-30R
Waveform Type Sine wave
Topology Double Conversion On-Line
Transfer Time Not specified
Bypass Type Internal Bypass (Automatic and Manual)
Crest Factor 3:1
Harmonic Distortion <2%
Battery Type Lead-Acid • Recharge: 1.5 h (typical) • Life: 3–5 years • RBC Qty: 1 • Replacement: APCRBC140 • Charge power: 556 W rated
Extendable Runtime Yes
Surge Energy Rating 480 J
Acoustic Noise 55 dBA
Thermal Dissipation 1047 BTU/h
Operating Temperature 0–40 °C (32–104 °F)
Operating Humidity 0–95% non-condensing
Altitude 0–10,000 ft operating
Communications USB compatible, EPO, Audible/visible alarms, 1 free SmartSlot, Pre-installed Network Management Card 3 with environmental monitoring
Certifications ENERGY STAR V2.0 (USA), NOM, TAA compliance
Warranty 3 years repair or replace (excluding battery) and 2 years for battery
[/specifications]

[accessories]

Rack Mounting Hardware Included in the box
Rack Mounting Brackets Included in the box
Rack Mounting Support Rails Included in the box
USB Cable Included in the box
Documentation Documentation CD, User Manual, Installation guide, Warranty card
Web/SNMP Management Card Pre-installed in the unit
[/accesories]

The APC Smart-UPS On-Line SRT5KRMXLTUS delivers continuous double-conversion protection in a compact 3U rackmount design. Rated 5400 VA / 4800 W at 208/240 V, it provides clean sine wave output, Internal Bypass (Automatic and Manual), and a pre-installed Network Management Card 3 with environmental monitoring—ensuring stable power and centralized visibility for servers, storage, and network devices.

  • Double Conversion Online – Regenerates AC power to deliver a low-distortion sine wave for sensitive IT loads.
  • Versatile NEMA Outlets – 2x L6-20R and 2x L6-30R support higher-current equipment and flexible distribution.
  • Internal Bypass – Automatic and manual bypass help maintain power to the load during certain UPS events.
  • Remote Management – Pre-installed Network Management Card 3 enables Ethernet monitoring and environmental inputs.
  • Fast Recovery – Typical battery recharge is about 1.5 hours, helping restore protection quickly.
  • ENERGY STAR® V2.0 – High efficiency aligned with recognized UPS standards.

Power Conditioning: Continuous AC-DC-AC conversion isolates connected equipment from sags, surges, and noise. Output harmonic distortion is less than 2%, and a 3:1 crest factor accommodates transient inrush without compromising stability.

Energy System: The lead-acid battery system supports extendable runtime and features a rated charge power of 556 W with a typical recharge time of 1.5 hours. Audible/visible alarms prioritized by severity and Emergency Power Off (EPO) streamline operational responses.

Distribution & Interfaces: Operation at 208/240 V with L6-20R and L6-30R receptacles fits mixed rack loads, while the factory-installed Network Management Card 3, USB connectivity, and SmartSlot™ architecture provide flexible management and environmental monitoring.

  • Enterprise racks requiring regulated 208/240 V sine wave power
  • Server, storage, and core network devices with higher-current connections
  • Sites needing centralized, Ethernet-based monitoring and fast recharge
  • Environments within 32–104 °F (0–40 °C), up to 95% RH non-condensing

Q1: How is the SRT5KRMXLTUS installed?
A: It is a 3U rack-mounted UPS and ships with rack mounting hardware, brackets, support rails, USB cable, and documentation. Input uses a NEMA L6-30P with a 10 ft (3.05 m) cord.

Q2: What performance can I expect?
A: Capacity is 5400 VA / 4800 W with sine wave output at 208/240 V. Runtime depends on load and any external battery packs—refer to the APC runtime graph for precise values; actual results vary by environment and battery condition.

Q3: How is it managed?
A: A pre-installed Network Management Card 3 enables remote monitoring/control and environmental inputs. USB provides local access, and prioritized alarms plus EPO support safe operations.

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc]

5400 VA / 4800 W, Double Conversion Online, 2x NEMA L6-20R + 2x NEMA L6-30R, Pre-installed Network Management Card 3

[/shortdesc]

[properties]

Brand APC by Schneider Electric
Model SRT5KRMXLTUS
Product Type Smart-UPS On-Line, Double Conversion
Form Factor Rackmount 3U
Dimensions (H x W x D) 5.1" x 17.0" x 28.3" (130 x 432 x 719 mm)
Weight 123 lb (55.79 kg)
Color Black
Number of Rack Units 3U
Cable Length 10 ft (3.05 m)
Cooling Not specified
[/properties]

[specifications]

Capacity 5400 VA / 4800 W
Input Voltage 208 V (other: 240 V) • Adjustable (half load): 100–275 V
Input Connection Type NEMA L6-30P
Input Frequency 40–70 Hz auto-sensing
Output Voltage 208 V (other: 240 V)
Output Connections 2 × NEMA L6-20R, 2 × NEMA L6-30R
Waveform Type Sine wave
Topology Double Conversion On-Line
Transfer Time Not specified
Bypass Type Internal Bypass (Automatic and Manual)
Crest Factor 3:1
Harmonic Distortion <2%
Battery Type Lead-Acid • Recharge: 1.5 h (typical) • Life: 3–5 years • RBC Qty: 1 • Replacement: APCRBC140 • Charge power: 556 W rated
Extendable Runtime Yes
Surge Energy Rating 480 J
Acoustic Noise 55 dBA
Thermal Dissipation 1047 BTU/h
Operating Temperature 0–40 °C (32–104 °F)
Operating Humidity 0–95% non-condensing
Altitude 0–10,000 ft operating
Communications USB compatible, EPO, Audible/visible alarms, 1 free SmartSlot, Pre-installed Network Management Card 3 with environmental monitoring
Certifications ENERGY STAR V2.0 (USA), NOM, TAA compliance
Warranty 3 years repair or replace (excluding battery) and 2 years for battery
[/specifications]

[accessories]

Rack Mounting Hardware Included in the box
Rack Mounting Brackets Included in the box
Rack Mounting Support Rails Included in the box
USB Cable Included in the box
Documentation Documentation CD, User Manual, Installation guide, Warranty card
Web/SNMP Management Card Pre-installed in the unit
[/accesories]
Overview

The APC Smart-UPS On-Line SRT5KRMXLTUS delivers continuous double-conversion protection in a compact 3U rackmount design. Rated 5400 VA / 4800 W at 208/240 V, it provides clean sine wave output, Internal Bypass (Automatic and Manual), and a pre-installed Network Management Card 3 with environmental monitoring—ensuring stable power and centralized visibility for servers, storage, and network devices.

Key Features & Benefits
  • Double Conversion Online – Regenerates AC power to deliver a low-distortion sine wave for sensitive IT loads.
  • Versatile NEMA Outlets – 2x L6-20R and 2x L6-30R support higher-current equipment and flexible distribution.
  • Internal Bypass – Automatic and manual bypass help maintain power to the load during certain UPS events.
  • Remote Management – Pre-installed Network Management Card 3 enables Ethernet monitoring and environmental inputs.
  • Fast Recovery – Typical battery recharge is about 1.5 hours, helping restore protection quickly.
  • ENERGY STAR® V2.0 – High efficiency aligned with recognized UPS standards.
Technical Deep Dive

Power Conditioning: Continuous AC-DC-AC conversion isolates connected equipment from sags, surges, and noise. Output harmonic distortion is less than 2%, and a 3:1 crest factor accommodates transient inrush without compromising stability.

Energy System: The lead-acid battery system supports extendable runtime and features a rated charge power of 556 W with a typical recharge time of 1.5 hours. Audible/visible alarms prioritized by severity and Emergency Power Off (EPO) streamline operational responses.

Distribution & Interfaces: Operation at 208/240 V with L6-20R and L6-30R receptacles fits mixed rack loads, while the factory-installed Network Management Card 3, USB connectivity, and SmartSlot™ architecture provide flexible management and environmental monitoring.

Ideal Applications
  • Enterprise racks requiring regulated 208/240 V sine wave power
  • Server, storage, and core network devices with higher-current connections
  • Sites needing centralized, Ethernet-based monitoring and fast recharge
  • Environments within 32–104 °F (0–40 °C), up to 95% RH non-condensing
Frequently Asked Questions (FAQs)

Q1: How is the SRT5KRMXLTUS installed?
A: It is a 3U rack-mounted UPS and ships with rack mounting hardware, brackets, support rails, USB cable, and documentation. Input uses a NEMA L6-30P with a 10 ft (3.05 m) cord.

Q2: What performance can I expect?
A: Capacity is 5400 VA / 4800 W with sine wave output at 208/240 V. Runtime depends on load and any external battery packs—refer to the APC runtime graph for precise values; actual results vary by environment and battery condition.

Q3: How is it managed?
A: A pre-installed Network Management Card 3 enables remote monitoring/control and environmental inputs. USB provides local access, and prioritized alarms plus EPO support safe operations.
