APC SMX2200RMLVUS - Smart-UPS X 2200VA Rack/Tower Convertible Line-Interactive UPS
Clique ou role para ampliar
Toque ou belisque para ampliar
APC SMX2200RMLVUS - Smart-UPS X 2200VA Rack/Tower Convertible Line-Interactive UPS
Clique ou role para ampliar
Toque ou belisque para ampliar
APC SMX2200RMLVUS - Smart-UPS X 2200VA Rack/Tower Convertible Line-Interactive UPS
Clique ou role para ampliar
Toque ou belisque para ampliar
APC SMX2200RMLVUS - Smart-UPS X 2200VA Rack/Tower Convertible Line-Interactive UPS
APC SMX2200RMLVUS - Smart-UPS X 2200VA Rack/Tower Convertible Line-Interactive UPS

APC SMX2200RMLVUS - Smart-UPS X 2200VA Rack/Tower Convertible Line-Interactive UPS

por APC
Desconto de 31%
R$ 42.780,00
R$ 29.316,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc] 2200VA / 1980W, Line-Interactive, Pure Sine Wave, 6x NEMA 5-15R + 2x NEMA 5-20R, SmartSlot, Extended Runtime [/shortdesc]

[properties]

Brand APC by Schneider Electric
Model SMX2200RMLVUS
Product Type Smart-UPS X, Line-Interactive (Extended runtime)
Form Factor Rack/Tower Convertible 2U
Dimensions (H x W x D) 3.3" x 17.0" x 26.3" (8.5 x 43.18 x 66.7 cm)
Weight 84.77 lb (38.45 kg)
Color Black
Number of Rack Units 2U
Cable Length 8 ft (2.4 m)
Mounting Rack-mounted
[/properties]

[specifications]

Capacity 2200 VA / 1980 W (Max configurable: 2200 VA / 1980 W)
Input Voltage 120 V (other: 100 V, 110 V, 127 V) • Operating range: 70–153 V
Input Connection Type NEMA L5-30P
Input Frequency 50/60 Hz ±3 Hz, auto-sensing
Output Voltage 120 V (other: 100 V, 110 V, 127 V)
Output Connections 6 × NEMA 5-15R, 2 × NEMA 5-20R
Topology / Waveform Line-Interactive • Sine wave • <5% THD
Transfer Time 2–4 ms (typ. 4 ms, max 8 ms)
Output Frequency 50/60 Hz ±3 Hz (sync to mains)
Battery Type Lead-Acid • Typical recharge 3 h • Life 3–5 years • Extendable runtime: Yes
Replacement Battery APCRBC117US • RBC qty: 1 • Charge power: 233 W (rated)
Surge Energy Rating 540 J
Acoustic Noise 55 dBA
Thermal Dissipation 268 BTU/h (online)
Operating Environment 0–40 °C (32–104 °F) • 0–95% RH (non-cond.) • Altitude 0–10,000 ft
Communications Multi-function LCD, LED indicators, USB, RS-232, EPO, 1× SmartSlot
Certifications BSMI, CSA, NOM, TÜV, VCCI Class A, TAA compliant
Warranty 3 years repair or replace (excluding battery) and 2 years for battery
[/specifications]

[accesories]

Rack Mounting Hardware & Brackets Included in the box
Rack Mounting Support Rails Included in the box
Removable Support Feet Included in the box
Smart-UPS Signalling RS-232 Cable Included in the box
USB Cable Included in the box
Documentation Installation guide, Documentation CD, CD with software
[/accesories]

The APC Smart-UPS X SMX2200RMLVUS is a high-performance 2U rack/tower convertible UPS delivering 2200VA / 1980W of reliable protection for IT systems. Designed with line-interactive topology, sine wave output, and extended runtime capability, it ensures business continuity in demanding environments. Featuring SmartSlot support, LCD control panel, and robust surge protection, this UPS is built for enterprise-level power security.

  • 2200VA / 1980W Capacity: Provides dependable power backup for enterprise IT environments.
  • Pure Sine Wave Output: Maintains clean and stable power delivery for sensitive hardware.
  • Extended Runtime Support: Expandable battery options enable longer protection during outages.
  • Rack/Tower Convertible Design: Flexible deployment for rack-mounted or tower-based setups.
  • SmartSlot Expansion: Supports optional management cards for advanced monitoring.
  • Multi-function LCD Panel: Real-time system status and easy control interface.

The SMX2200RMLVUS leverages line-interactive architecture with AVR to stabilize fluctuating voltages before they affect connected devices. This minimizes battery usage during common power events, ensuring longer operational life and greater system reliability.

Its pure sine wave output guarantees compatibility with critical IT equipment, including active PFC power supplies, delivering consistent performance during switchover events. The UPS also integrates a SmartSlot, enabling installation of optional network management cards for remote monitoring and secure system integration.

Extended runtime capability is a defining feature of this unit. With external battery pack compatibility, businesses can scale power availability based on operational needs, making it suitable for applications where uptime is paramount.

  • Enterprise servers and storage systems
  • Data center racks and network infrastructure
  • Healthcare IT and mission-critical systems
  • Finance and retail operations requiring extended backup time

Q1: How is the SMX2200RMLVUS installed?
A: This UPS is a 2U rack/tower convertible system with included mounting hardware and support feet for flexible installation.

Q2: What performance can I expect?
A: The unit delivers 2200VA / 1980W of sine wave output with AVR. Runtime depends on connected load and can be extended with external battery packs. Consult APC runtime charts for specific details.

Q3: How can the UPS be managed?
A: The UPS features an intuitive LCD panel for local management and includes a SmartSlot for optional network management cards, enabling remote monitoring and control.

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc] 2200VA / 1980W, Line-Interactive, Pure Sine Wave, 6x NEMA 5-15R + 2x NEMA 5-20R, SmartSlot, Extended Runtime [/shortdesc]

[properties]

Brand APC by Schneider Electric
Model SMX2200RMLVUS
Product Type Smart-UPS X, Line-Interactive (Extended runtime)
Form Factor Rack/Tower Convertible 2U
Dimensions (H x W x D) 3.3" x 17.0" x 26.3" (8.5 x 43.18 x 66.7 cm)
Weight 84.77 lb (38.45 kg)
Color Black
Number of Rack Units 2U
Cable Length 8 ft (2.4 m)
Mounting Rack-mounted
[/properties]

[specifications]

Capacity 2200 VA / 1980 W (Max configurable: 2200 VA / 1980 W)
Input Voltage 120 V (other: 100 V, 110 V, 127 V) • Operating range: 70–153 V
Input Connection Type NEMA L5-30P
Input Frequency 50/60 Hz ±3 Hz, auto-sensing
Output Voltage 120 V (other: 100 V, 110 V, 127 V)
Output Connections 6 × NEMA 5-15R, 2 × NEMA 5-20R
Topology / Waveform Line-Interactive • Sine wave • <5% THD
Transfer Time 2–4 ms (typ. 4 ms, max 8 ms)
Output Frequency 50/60 Hz ±3 Hz (sync to mains)
Battery Type Lead-Acid • Typical recharge 3 h • Life 3–5 years • Extendable runtime: Yes
Replacement Battery APCRBC117US • RBC qty: 1 • Charge power: 233 W (rated)
Surge Energy Rating 540 J
Acoustic Noise 55 dBA
Thermal Dissipation 268 BTU/h (online)
Operating Environment 0–40 °C (32–104 °F) • 0–95% RH (non-cond.) • Altitude 0–10,000 ft
Communications Multi-function LCD, LED indicators, USB, RS-232, EPO, 1× SmartSlot
Certifications BSMI, CSA, NOM, TÜV, VCCI Class A, TAA compliant
Warranty 3 years repair or replace (excluding battery) and 2 years for battery
[/specifications]

[accesories]

Rack Mounting Hardware & Brackets Included in the box
Rack Mounting Support Rails Included in the box
Removable Support Feet Included in the box
Smart-UPS Signalling RS-232 Cable Included in the box
USB Cable Included in the box
Documentation Installation guide, Documentation CD, CD with software
[/accesories]
Overview

The APC Smart-UPS X SMX2200RMLVUS is a high-performance 2U rack/tower convertible UPS delivering 2200VA / 1980W of reliable protection for IT systems. Designed with line-interactive topology, sine wave output, and extended runtime capability, it ensures business continuity in demanding environments. Featuring SmartSlot support, LCD control panel, and robust surge protection, this UPS is built for enterprise-level power security.

Key Features & Benefits
  • 2200VA / 1980W Capacity: Provides dependable power backup for enterprise IT environments.
  • Pure Sine Wave Output: Maintains clean and stable power delivery for sensitive hardware.
  • Extended Runtime Support: Expandable battery options enable longer protection during outages.
  • Rack/Tower Convertible Design: Flexible deployment for rack-mounted or tower-based setups.
  • SmartSlot Expansion: Supports optional management cards for advanced monitoring.
  • Multi-function LCD Panel: Real-time system status and easy control interface.
Technical Deep Dive

The SMX2200RMLVUS leverages line-interactive architecture with AVR to stabilize fluctuating voltages before they affect connected devices. This minimizes battery usage during common power events, ensuring longer operational life and greater system reliability.

Its pure sine wave output guarantees compatibility with critical IT equipment, including active PFC power supplies, delivering consistent performance during switchover events. The UPS also integrates a SmartSlot, enabling installation of optional network management cards for remote monitoring and secure system integration.

Extended runtime capability is a defining feature of this unit. With external battery pack compatibility, businesses can scale power availability based on operational needs, making it suitable for applications where uptime is paramount.

Ideal Applications
  • Enterprise servers and storage systems
  • Data center racks and network infrastructure
  • Healthcare IT and mission-critical systems
  • Finance and retail operations requiring extended backup time
Frequently Asked Questions (FAQs)

Q1: How is the SMX2200RMLVUS installed?
A: This UPS is a 2U rack/tower convertible system with included mounting hardware and support feet for flexible installation.

Q2: What performance can I expect?
A: The unit delivers 2200VA / 1980W of sine wave output with AVR. Runtime depends on connected load and can be extended with external battery packs. Consult APC runtime charts for specific details.

Q3: How can the UPS be managed?
A: The UPS features an intuitive LCD panel for local management and includes a SmartSlot for optional network management cards, enabling remote monitoring and control.
