APC APDU9959NA3 - NetShelter Switched Rack PDU 9K 0U 20A 208V
Clique ou role para ampliar
Toque ou belisque para ampliar
APC APDU9959NA3 - NetShelter Switched Rack PDU 9K 0U 20A 208V
Clique ou role para ampliar
Toque ou belisque para ampliar
APC APDU9959NA3 - NetShelter Switched Rack PDU 9K 0U 20A 208V
Clique ou role para ampliar
Toque ou belisque para ampliar
APC APDU9959NA3 - NetShelter Switched Rack PDU 9K 0U 20A 208V
APC APDU9959NA3 - NetShelter Switched Rack PDU 9K 0U 20A 208V

APC APDU9959NA3 - NetShelter Switched Rack PDU 9K 0U 20A 208V

por APC
Desconto de 35%
R$ 27.180,00
R$ 17.712,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc]

24 outlets (21 C13/C15, 3 C19/C21), 20A input, 208V output, Switched PDU, SNMP & Redfish remote management

[/shortdesc]

[properties]

Brand APC by Schneider Electric
Model APDU9959NA3
Product Type NetShelter Switched Rack PDU
Form Factor 0U Vertical
Dimensions (H x W x D) 70.7" x 2.2" x 1.8" (1797 x 55 x 46 mm)
Weight 12.37 lb (5.61 kg)
Color Black
Number of Rack Units 0U
Mounting Mode Vertical, Side Mountable
Cooling Not specified
[/properties]

[specifications]

PDU Type Switched (9K Series)
Input Voltage 200 V / 208 V
Output Voltage 200 V / 208 V
Input Plug Type IEC 60320 L6-20P
Input Frequency 50/60 Hz
Line Rated Current 16 A (Max 20 A)
Load Capacity 3300 VA
Outlets 21 × C13/C15, 3 × C19/C21
Communication Ports SNMP, Redfish, 10/100/1000BASE-T
Operating Temperature 23–140 °F (-5–60 °C)
Storage Temperature -13–149 °F (-25–65 °C)
Operating Humidity 5–95%
Storage Humidity 5–95%
Operating Altitude 0–10,000 ft
Storage Altitude 0–50,000 ft
Compliance cUL Listed, FCC Part 15 Class A, PSE, IEC 62368-1, RoHS (Compliant with Exemptions), REACh
Warranty 3 years repair or replace
[/specifications]

[accessories]

Installation Guide Included in the box
Rack Mounting Brackets Included in the box
Safety Guide Included in the box
[/accesories]

The APC NetShelter APDU9959NA3 is a Switched Rack PDU designed for high-density IT environments. Offering a vertical 0U form factor, it combines 24 outlets with advanced remote management capabilities, ensuring reliable power distribution and control for mission-critical network hardware.

  • High-Density Outlets: 21 C13/C15 and 3 C19/C21 outlets for flexible device connectivity.
  • Switched Control: Individual outlet-level switching improves energy efficiency and security.
  • Advanced Network Management: SNMP and Redfish protocols enable integration with modern DCIM tools.
  • 0U Vertical Mounting: Saves rack space and supports optimized airflow in cabinets.
  • Robust Build: Certified to IEC 62368-1 with cUL, FCC, and PSE compliance.

The APDU9959NA3 utilizes switched PDU technology, enabling remote outlet-level on/off control and sequencing. This allows data center managers to power-cycle unresponsive equipment or manage loads more efficiently without manual intervention.

Integrated SNMP and Redfish connectivity ensure compatibility with diverse monitoring platforms, giving IT staff visibility into power usage and device performance. With 10/100/1000BASE-T Ethernet support, it provides secure, real-time communication with management systems.

Its vertical 0U mounting reduces rack footprint while maximizing equipment space. Combined with a 20A, 208V input capacity and 3300 VA load support, it delivers reliable performance in demanding IT environments.

  • Enterprise data centers requiring switched outlet control
  • Network closets with dense server deployments
  • Colocation facilities needing remote power management
  • Industries prioritizing uptime: finance, healthcare, and telecommunications

Q1: How is the APDU9959NA3 installed?
A: It is designed for vertical 0U mounting with included brackets, fitting neatly into standard APC NetShelter racks.

Q2: What performance does it provide?
A: It supports a 20A input at 208V with a maximum load capacity of 3300 VA. Runtime depends on connected UPS systems and equipment draw.

Q3: How can it be managed?
A: The unit supports SNMP and Redfish protocols over gigabit Ethernet, enabling seamless integration with monitoring platforms for remote visibility and control.

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc]

24 outlets (21 C13/C15, 3 C19/C21), 20A input, 208V output, Switched PDU, SNMP & Redfish remote management

[/shortdesc]

[properties]

Brand APC by Schneider Electric
Model APDU9959NA3
Product Type NetShelter Switched Rack PDU
Form Factor 0U Vertical
Dimensions (H x W x D) 70.7" x 2.2" x 1.8" (1797 x 55 x 46 mm)
Weight 12.37 lb (5.61 kg)
Color Black
Number of Rack Units 0U
Mounting Mode Vertical, Side Mountable
Cooling Not specified
[/properties]

[specifications]

PDU Type Switched (9K Series)
Input Voltage 200 V / 208 V
Output Voltage 200 V / 208 V
Input Plug Type IEC 60320 L6-20P
Input Frequency 50/60 Hz
Line Rated Current 16 A (Max 20 A)
Load Capacity 3300 VA
Outlets 21 × C13/C15, 3 × C19/C21
Communication Ports SNMP, Redfish, 10/100/1000BASE-T
Operating Temperature 23–140 °F (-5–60 °C)
Storage Temperature -13–149 °F (-25–65 °C)
Operating Humidity 5–95%
Storage Humidity 5–95%
Operating Altitude 0–10,000 ft
Storage Altitude 0–50,000 ft
Compliance cUL Listed, FCC Part 15 Class A, PSE, IEC 62368-1, RoHS (Compliant with Exemptions), REACh
Warranty 3 years repair or replace
[/specifications]

[accessories]

Installation Guide Included in the box
Rack Mounting Brackets Included in the box
Safety Guide Included in the box
[/accesories]
Overview

The APC NetShelter APDU9959NA3 is a Switched Rack PDU designed for high-density IT environments. Offering a vertical 0U form factor, it combines 24 outlets with advanced remote management capabilities, ensuring reliable power distribution and control for mission-critical network hardware.

Key Features & Benefits
  • High-Density Outlets: 21 C13/C15 and 3 C19/C21 outlets for flexible device connectivity.
  • Switched Control: Individual outlet-level switching improves energy efficiency and security.
  • Advanced Network Management: SNMP and Redfish protocols enable integration with modern DCIM tools.
  • 0U Vertical Mounting: Saves rack space and supports optimized airflow in cabinets.
  • Robust Build: Certified to IEC 62368-1 with cUL, FCC, and PSE compliance.
Technical Deep Dive

The APDU9959NA3 utilizes switched PDU technology, enabling remote outlet-level on/off control and sequencing. This allows data center managers to power-cycle unresponsive equipment or manage loads more efficiently without manual intervention.

Integrated SNMP and Redfish connectivity ensure compatibility with diverse monitoring platforms, giving IT staff visibility into power usage and device performance. With 10/100/1000BASE-T Ethernet support, it provides secure, real-time communication with management systems.

Its vertical 0U mounting reduces rack footprint while maximizing equipment space. Combined with a 20A, 208V input capacity and 3300 VA load support, it delivers reliable performance in demanding IT environments.

Ideal Applications
  • Enterprise data centers requiring switched outlet control
  • Network closets with dense server deployments
  • Colocation facilities needing remote power management
  • Industries prioritizing uptime: finance, healthcare, and telecommunications
Frequently Asked Questions (FAQs)

Q1: How is the APDU9959NA3 installed?
A: It is designed for vertical 0U mounting with included brackets, fitting neatly into standard APC NetShelter racks.

Q2: What performance does it provide?
A: It supports a 20A input at 208V with a maximum load capacity of 3300 VA. Runtime depends on connected UPS systems and equipment draw.

Q3: How can it be managed?
A: The unit supports SNMP and Redfish protocols over gigabit Ethernet, enabling seamless integration with monitoring platforms for remote visibility and control.
