APC AP9614 Dry Contact I/O SmartSlot UPS Management Card
APC AP9614 Dry Contact I/O SmartSlot UPS Management Card

APC AP9614 Dry Contact I/O SmartSlot UPS Management Card

por APC
Desconto de 34%
R$ 6.300,00
R$ 4.176,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc] APC Dry Contact I/O SmartSlot Card for UPS sensors, self powered via SmartSlot, 24 V rated, 0-200 mA line current, 0U form factor, 0.159 m cable length [/shortdesc]

[properties]

Model AP9614
Product Name APC Dry Contact I/O SmartSlot Card
Product Type UPS Management Adapter; Dry contact
Range of Product Management Options and Cables
Application / Usage UPS
Management Monitoring & Control
Interfaces / Ports USB; Network (RJ-45)
Number of Network (RJ-45) Ports 2
USB Yes
Power Supply Type Self powered via SmartSlot
Rated Voltage 24 V
Line Rated Current 0-200 mA
Cable Length 0.522 ft (0.159 m)
Rack Height / Number of Rack Units 0U
Mounting Mode Not rack-mountable
Height 1.5 in (3.8 cm)
Width 4.8 in (12.1 cm)
Depth 5.04 in (12.8 cm)
Net Weight 0.44 lb (0.20 kg)
Compatibility APC SmartSlot 160kVA UPS
Mercury Free Yes

[/properties]

[specifications]

I/O Capacity 6 configurable output relays; 4 input contacts; 2 Universal I/O (UIO) ports for optional environmental sensors and Dry Contact I/O Accessory
Rated Voltage 24 V
Line Rated Current 0-200 mA
Operating Temperature 32-104 °F (0-40 °C)
Storage Temperature 5-149 °F (-15-65 °C)
Operating Altitude 0-10000 ft
Storage Altitude 0-50000 ft (0-15240 m)

[/specifications]

[accesories]

Included UPS Management Adapter; User manual; USB cable (included in the box)
Optional - Environmental Sensors Optional environmental sensors via Universal I/O (UIO) ports
Optional - Dry Contact I/O Accessory Dry Contact I/O Accessory providing 2 additional dry contact input and relay output interfaces

[/accesories]

The APC AP9614 Dry Contact I/O SmartSlot Card enables centralized monitoring of external UPS environmental sensors, output relays, and input contacts. It is designed to integrate critical dry contact signals directly into your UPS management system, helping you react faster to environmental and power events. Self powered through the SmartSlot interface, it simplifies deployment with no additional power supply required.

  • External Sensor and Contact Integration: Monitor external UPS environmental sensors, output relays, and input contacts through a dedicated dry contact interface (6 configurable output relays and 4 input contacts).
  • SmartSlot-Powered Design: Self powered via the UPS SmartSlot, eliminating the need for separate power cabling or adapters.
  • Compact 0U Form Factor: The 0U design is not rack-mountable, offering flexible installation while adding powerful monitoring capability.
  • Reliable Electrical Performance: Rated for 24 V with a 0-200 mA line current, perfectly suited for standard dry contact monitoring applications.
  • Ready-to-Install Package: Supplied with the UPS Management Adapter, user manual, and necessary USB cable for straightforward integration and configuration.
  • UPS installations that require monitoring of external environmental sensors, relays, and dry contact inputs.
  • Network or equipment rooms where UPS status and external contact alarms need to be consolidated in one management interface.
  • Facilities teams seeking clearer visibility into external conditions that can impact UPS performance and protected loads.
  • Sites standardizing on Management Options and Cables for consistent UPS accessory integration.
  • Product type: Dry contact I/O card
  • Range of product: Management Options and Cables
  • Rated voltage: 24 V
  • Line rated current: 0-200 mA
  • Power supply type: Self powered via SmartSlot
  • Cable length: 0.522 ft (0.159 m)
  • Number of rack units: 0U
  • Height: 1.5 in (3.8 cm)
  • Width: 4.8 in (12.1 cm)
  • Depth: 5.04 in (12.8 cm)
  • Net weight: 0.44 lb (0.20 kg)
  • Operating temperature: 32-104 °F (0-40 °C)
  • Operating altitude: 0-10000 ft
  • Storage temperature: 5-149 °F (-15-65 °C)
  • Storage altitude: 0-50000 ft (0-15240 m)
  • Provided equipment: UPS Management Adapter, User manual, and USB cable

Strengthen visibility into external UPS sensors and contacts with the APC AP9614 Dry Contact I/O SmartSlot Card. Order today to streamline your UPS monitoring.
