AIR-AP1832I-X-K9
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Aironet 1832I-X-K9 Access Point Overview
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
The AIR-AP1832I-X-K9 is part of the Cisco Aironet 1830 Series, designed for small to medium-sized networks. It supports 802.11ac Wave 2, offering 3x3 MIMO with two spatial streams for enhanced performance. The model features internal antennas, with 2.4 GHz (3 dBi) and 5 GHz (5 dBi) omnidirectional coverage. It supports MRC, 802.11ac beamforming, and high data rates up to 867 Mbps on 80 MHz channels. PoE and USB 2.0 are included.
Compare with similar items
Part Number |
AIR-AP1832I-A-K9 |
AIR-AP1832I-A-K9C |
| Description | 802.11ac Wave 2 AP, 3x3:2 | 802.11ac Wave 2 AP, 3x3:2 ★ Model number ending in C is, by default, factory-shipped with a Cisco Mobility Express software image. |
| Integrated antenna | Yes | Yes |
Specifications
AIR-AP1832I-X-K9 Specification |
|
| Software | Cisco Unified Wireless Network Software Release with AireOS wireless controllers:8.1.121.0 or later for the Cisco Aironet 1830 Series Access Points |
| Deployment modes | Centralized, standalone, sniffer, Cisco FlexConnect™, monitor, OfficeExtend, mesh |
| Supported wireless LAN controllers | Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Cisco Catalyst®6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco 5520 Series Wireless Controllers, Cisco Flex® 7500 Series Wireless Controllers, Cisco 8500 Series Wireless Controllers, Cisco 8540 Series Wireless Controllers, Cisco 5760 Wireless LAN Controller, Cisco Catalyst 3650 and 3850 Series Switches with integrated controller Cisco Mobility Express |
|
802.11n version 2.0 (and related) capabilities |
3x3 MIMO with two spatial streams Maximal ratio combining (MRC)20- and 40-MHz channels PHY data rates up to 300 Mbps (40 MHz with 5 GHz) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) 802.11 dynamic frequency selection (DFS) Cyclic shift diversity (CSD) support |
| 802.11ac Wave 1 and 2 capabilities | 3x3 MIMO with two spatial streams, single-user or multiuser MIMOMRC 802.11ac beamforming (transmit beamforming) 20-, 40-, and 80-MHz channels PHY data rates up to 867 Mbps (80 MHz in 5 GHz) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) 802.11 DFSCSD support |
| Integrated antenna | 2.4 GHz, gain 3 dBi, internal omni, horizontal beamwidth 360° 5 GHz, gain 5 dBi, internal omni, horizontal beamwidth 360° |
| Interfaces | 1 x 10/100/1000 BASE-T autosensing (RJ-45), Power over Ethernet (PoE) Management console port (RJ-45) USB 2.0 (enabled via future software) |
| Indicators | Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors |
| Dimensions(W x L x H) | Access point (without mounting bracket): 8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) |
| Weight | 3.12 lb (1.41 kg) |
| Environmental | Cisco Aironet 1830i Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C) Nonoperating (storage) altitude test: 25˚C, 15,000 ft. Operating temperature: 32° to 104°F (0° to 40°C) Operating humidity: 10% to 90% (noncondensing) Operating altitude test: 40˚C, 9843 ft. |
| System memory | 1 GB DRAM256 MB flash |
| Input power requirements | AP1830: 44 to 57 VDC Power supply and power injector: 100 to 240 VAC; 50 to 60 Hz |
| Power draw | 15.4W Note: When deployed using a PoE specification, the power drawn from the power sourcing equipment will be higher by some amount, depending on the length of the inter connecting cable. |
| Powering options | 802.3af/802.3at Enhanced PoE Cisco local power supply, AIR-PWR-C= Cisco power injector, AIR-PWRINJ5= (Note:This injector supports 802.3af only), AIR-PWRINJ6= Note: If 802.3af PoE is the source of power, the USB port is disabled. |
| Warranty | Limited lifetime hardware warranty |
