605-3 | Differential pressure indicating transmitter | range 0-3.0" w.c. | max. pressure 2 psi (13.79 kPa) | ±0.5% electrical accuracy | ±2% mechanical accuracy. | Dwyer
605-3 | Differential pressure indicating transmitter | range 0-3.0" w.c. | max. pressure 2 psi (13.79 kPa) | ±0.5% electrical accuracy | ±2% mechanical accuracy. | Dwyer

605-3 | Differential pressure indicating transmitter | range 0-3.0" w.c. | max. pressure 2 psi (13.79 kPa) | ±0.5% electrical accuracy | ±2% mechanical accuracy. | Dwyer

por Dwyer
R$ 13.437,50
R$ 11.354,75
Pedir por e-mail
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x
See catalog product page for full listing

Differential pressure indicating transmitter | range 0-3.0" w.c. | max. pressure 2 psi (13.79 kPa) | ±0.5% electrical accuracy | ±2% mechanical accuracy.

Series 605 Magnehelic® Differential Pressure Indicating Transmitter

Same Size as Standard Magnehelic® Differential Pressure Gage

The Series 605 Magnehelic® Indicating Transmitter provides for both visual monitoring and electronic control of very low differential pressure. The Series 605 is ideal for control applications in building HVAC systems where local indication is desired during routine maintenance checks or necessary when trouble shooting the system. The easily read dial gage is complimented by the two-wire, 4 to 20 mA control signal utilizing the time-proven Dwyer® Magnehelic® gage mechanical design and Series 600 transmitter technology. The two-wire design with terminal strip on the rear simplifies connection in any 4 to 20 mA control loop powered by a 10 to 35 VDC supply.

NIST CALIBRATION available in Product Configurator.

Please see Series AT-605 for ATEX approved.

  • Monitor pressures in ducts, rooms, or total building pressures
  • Filter monitoring
  • Local indication of clean room pressures with process signal sent to control room
  • Easy to read gage permits viewing from far away
  • Patented design provides quick response to pressure changes means no delay in signaling and alerting to critical situations
  • Durable and rugged housing and high-quality components combined provides long-service life and minimized down-time
  • Optional stainless steel bezel is the same installation diameter as Magnehelic® gage and simplifies field upgrade to 605 indicating transmitter

Series
605 Magnehelic® Differential Pressure Indicating Transmitter
Category/Type
Pressure
Type
Differential Pressure
Series
605 Magnehelic® Differential Pressure Indicating Transmitter
GAGE SPECIFICATIONS
Service
Air and non-combustible; compatible gases.
Wetted Materials
Consult factory.
Accuracy
See Ordering page.
Stability
±1% FS/yr.
Pressure Limits
See Ordering page.
Temperature Limits
20 to 120°F (-6.67 to 48.9°C).
Process Connections
1/8" female NPT.
Size
4" (101.6 mm) dial face; 5" (127 mm) OD x 2-11/16" (68.3 mm).
Weight
1 lb; 12.6 oz (811 g).
Agency Approvals
CE.
TRANSMITTER SPECIFICATIONS
Accuracy
See Ordering page (includes linearity; hysteresis; and repeatability).
Temperature Limits
20 to 120°F (-6.67 to 48.9°C).
Compensated Temperature Range
32 to 120°F (0 to 48.9°C).
Thermal Effect
±0.025% FS/°F (0.045% FS/°C).
Power Requirements
10 to 35 VDC (2-wire).
Output Signal
4 to 20 mA.
Zero and Span Adjustments
Protected potentiometers.
Loop Resistance
DC: 0 to 1250 Ω maximum.
Current Consumption
DC: 38 mA maximum.
Electrical Connections
Screw terminal block.
Mounting Orientation
Diaphragm in vertical position. Consult factory for other position orientations.

Resources

Instruction ManualSeries 605 Catalog Page605 More Info ^^Differential pressure indicating transmitter, range 0-3.0" w.c., max. pressure 2 psi (13.79 kPa), ±0.5% electrical accuracy, ±2% mechanical accuracy.^^
