"Upgrade your network infrastructure with the 10GBase-LR Lite SFP+ Optics Module. Designed to be Arista Compatible and featuring the SFP-10G-LRL-AR-ABA model, this module provides high-speed data transmission with enhanced reliability and compatibility."
"Maximize your network performance with the 10GBase-LR Lite SFP+ Optics Module. Arista Compatible and featuring the SFP-10G-LRL-AR-ABA model, this module offers reliable connectivity over long distances, ensuring smooth operation and optimized network efficiency."
Product Specifications for 10GBase-LR Lite SFP+ Optics Module Arista Compatible (Data Sheet)
| Specification |
Details |
| Model Number |
SFP-10G-LRL |
| Description |
10GBASE-LR Lite SFP+ Transceiver Module |
| Compatibility |
Fully compatible with Arista Networks equipment, including switches, routers, and network interface cards |
| Data Rate |
Supports up to 10.3 Gbps bi-directional data links |
| Wavelength |
1310 nm |
| Connector Type |
Duplex LC |
| Cable Type |
Single-Mode Fiber (SMF) |
| Maximum Distance |
Up to 1 km |
| Digital Diagnostics Monitoring (DDM) |
Supported |
| Operating Temperature Range |
0°C to 70°C |
| Compliance Standards |
- IEEE 802.3ae 10GBASE-LR- SFP+ Multi-Source Agreement (MSA)- RoHS 6 Compliant |
| Transmit Power |
-8.0 to +0.5 dBm |
| Receiver Sensitivity |
-14.0 dBm |
| Extinction Ratio |
3.5 dB |
| Power Budget |
6.0 dB |
| Dimensions |
Standard SFP+ form factor |
FAQs:
1. What is the primary application of the 10GBASE-LR Lite SFP+ Optics Module?
This module is designed for long-range data transmission over single-mode fiber, making it ideal for data centers, enterprise networks, and service provider applications requiring up to 10 Gbps speeds over distances up to 1 km.
2. Is this module hot-swappable?
Yes, the 10GBASE-LR Lite SFP+ Optics Module is hot-swappable, allowing for seamless installation or replacement without disrupting network operations.
3. Does this transceiver support Digital Diagnostics Monitoring (DDM)?
Yes, it features DDM, providing real-time monitoring of parameters such as temperature, voltage, and optical power, which aids in network management and troubleshooting.
4. What type of fiber cable is compatible with this module?
The module is compatible with single-mode fiber (SMF) cables, suitable for long-distance data transmission.
5. Is the 10GBASE-LR Lite SFP+ Optics Module compliant with industry standards?
Yes, it complies with IEEE 802.3ae 10GBASE-LR standards, SFP+ MSA, and is RoHS 6 compliant, ensuring compatibility and environmental safety.
