SK Hynix 3.84TB NVMe U.3 PCIe Gen 4.0 x4 RI SFF 2.5" 15mm SSD PE8110 Series for Supermicro Server with Tray

SK Hynix 3.84TB NVMe U.3 PCIe Gen 4.0 x4 RI SFF 2.5" 15mm SSD PE8110 Series for Supermicro Server with Tray

Note: This tray may vary depending on our inventory.

The SK Hynix PE8110 Series 3.84TB NVMe SSD is an enterprise-grade read-intensive storage solution designed for high-performance data center environments. Built on PCIe Gen4 x4 with NVMe 1.4 and a U.3 tri-mode interface, it delivers high throughput, low latency, and strong endurance for virtualization, cloud workloads, and read-heavy applications. It is compatible with Supermicro servers equipped with NVMe U.3/U.2 backplanes and the appropriate drive tray.

Other Related Part Numbers

HFS3T8GEETX070N, PE8110

Technical Specifications

• Capacity: 3.84TB
• Series: PE8110
• Interface: PCIe Gen4.0 x4, NVMe 1.4
• Form Factor: 2.5" SFF (15mm)
• Connector: U.3 (backward compatible with U.2)
• NAND Flash: 128-layer 3D TLC NAND
• Workload Type: Read Intensive (RI), ~1 DWPD

Performance

• Sequential Read: Up to ~6,200–6,500 MB/s
• Sequential Write: Up to ~3,800–4,000 MB/s
• Random Read: Up to ~1,000,000+ IOPS
• Random Write: Up to ~150,000–180,000 IOPS

Reliability & Features

• Endurance: ~1 DWPD
• MTBF: Up to ~2.5 million hours
• Power Loss Protection: Yes
• End-to-End Data Protection: Yes
• Encryption: AES 256-bit hardware encryption

Supermicro Server Compatibility

Supermicro H13 / X13 Series (PCIe Gen4 / Gen5 – Full Performance):
SYS-121H-TNR, SYS-221H-TN24R, SYS-621C-TN12R, AS-2125HS-TNR, AS-1115HS-TNR

Supermicro X12 / H12 Series (PCIe Gen4 – Full Performance):
SYS-120H-TNR, SYS-220H-TN24R, SYS-120C-TN10R, AS-1124US-TNR, AS-2024US-TNR

Supermicro X11 / H11 Series (PCIe Gen3 – Performance Limited):
SYS-6029P-C1R, SYS-1029U-TN10RT, SYS-2029U-TN24R, AS-1123US-TN9R, AS-2023US-TR4

Important Deployment Notes

• NVMe U.3/U.2 backplane required (SAS/SATA backplanes are not supported)
• Must be installed in a Supermicro 2.5" NVMe tray for proper fitment
• U.3 drives are backward compatible with U.2 infrastructure when properly cabled
• Performance scales depending on platform generation (Gen4 vs Gen3 systems)
• Requires strong airflow for proper thermal management

Summary

The SK Hynix PE8110 3.84TB NVMe SSD delivers enterprise-class performance and reliability for Supermicro servers, supporting multiple generations of platforms with NVMe-enabled backplanes. It is well suited for virtualization, cloud infrastructure, and high-performance read-intensive workloads.
