Restore the performance and reliability of your Dell EMC PowerEdge R640 server with the Dell RGP26 / 0RGP26 Dual-Socket Server Motherboard. Designed specifically for the PowerEdge R640 1U rack server platform, this motherboard supports 1st and 2nd Generation Intel Xeon Scalable processors, high-capacity DDR4 ECC memory, integrated enterprise management features, and flexible storage and networking configurations.
Engineered for data center and enterprise environments, the Dell RGP26 motherboard provides support for dual Intel Xeon Scalable processors, advanced memory scalability, PCIe Gen3 expansion capabilities, Dell PERC RAID controllers, and integrated iDRAC9 server management. Whether replacing a failed system board or refurbishing existing hardware, the RGP26 offers a reliable solution for maintaining PowerEdge R640 server deployments.
Compatible Part Numbers: RGP26, 0RGP26
KEY FEATURES
• Dell EMC PowerEdge R640 Server Motherboard (Systemboard)
• Dell Part Number: RGP26
• Dell DP/N: 0RGP26
• Dual FCLGA3647 CPU Sockets
• Intel C620 Series Server Chipset
• Supports 1st & 2nd Generation Intel Xeon Scalable Processors
• Supports Intel Xeon Bronze, Silver, Gold, and Platinum Processors
• Up to 28 Cores Per Processor
• Dual Processor Support
• 24 DDR4 ECC DIMM Slots
• RDIMM, LRDIMM, and NVDIMM-N Memory Support
• Up to 3TB Memory Capacity
• Integrated Dell iDRAC9 Management
• Embedded Dell PERC S140 RAID Support
• Dedicated Mini-PERC Expansion Slot
• Dell BOSS Boot Optimized Storage Support
• Designed Specifically for Dell EMC PowerEdge R640 Servers
TECHNICAL SPECIFICATIONS
• Form Factor: Dell PowerEdge R640 Proprietary System Board
• CPU Socket Type: Dual FCLGA3647
• Chipset: Intel C620 Series
• Supported Processor Generations: 1st & 2nd Gen Intel Xeon Scalable
• Maximum Processor Count: 2
• Memory Slots: 24 DDR4 DIMM Slots
• Memory Type: ECC RDIMM, LRDIMM, NVDIMM-N
• Maximum Memory Capacity: Up To 3TB
• Memory Speeds: Up To 2933 MT/s
• RAID Support: Dell PERC S140
• Remote Management: Dell iDRAC9 with Lifecycle Controller
• PCIe Support: PCIe Gen3 Expansion Via Riser Cards
MEMORY SUPPORT
• 24 DDR4 ECC DIMM Slots
• Up To 3TB DDR4 Using LRDIMMs
• Up To 1.5TB DDR4 Using RDIMMs
• Up To 192GB NVDIMM-N Configuration
• Registered DIMM (RDIMM) Support
• Load Reduced DIMM (LRDIMM) Support
• ECC Memory Support
• Up To 2933 MT/s Transfer Speeds
STORAGE & EXPANSION
• Embedded Dell PERC S140 Software RAID
• Dedicated Mini-PERC Controller Slot
• Compatible With PERC H330 RAID Controllers
• Compatible With PERC H730P RAID Controllers
• Compatible With PERC H740P RAID Controllers
• Dell BOSS M.2 Boot Storage Support
• Supports Up To 3 PCIe Gen3 Expansion Slots Through Dell Riser Assemblies
• Supports SATA, SAS, SSD, and NVMe Storage Configurations
NETWORKING & MANAGEMENT
• Integrated Dell iDRAC9 with Lifecycle Controller
• Dedicated iDRAC Management Port
• Support for Dell Network Daughter Cards (rNDC)
• Compatible With 1GbE, 10GbE, and 25GbE Networking Options
• VGA Display Output
• USB Connectivity
• Serial Port Support
COMPATIBLE SERVER PLATFORMS
• Dell EMC PowerEdge R640
• PowerEdge R640 4-Bay LFF Configurations
• PowerEdge R640 8-Bay SFF Configurations
• PowerEdge R640 10-Bay NVMe Configurations
• PowerEdge R640 Hybrid Storage Configurations
• PowerEdge R640 VMware vSphere Deployments
• PowerEdge R640 Microsoft Hyper-V Deployments
• PowerEdge R640 Virtualization Clusters
• PowerEdge R640 Database Servers
• PowerEdge R640 Software Defined Storage Platforms
COMPATIBLE PROCESSOR FAMILIES
• Intel Xeon Bronze 3100 Series
• Intel Xeon Bronze 3200 Series
• Intel Xeon Silver 4100 Series
• Intel Xeon Silver 4200 Series
• Intel Xeon Gold 5100 Series
• Intel Xeon Gold 6100 Series
• Intel Xeon Gold 6200 Series
• Intel Xeon Gold 6200R Series
• Intel Xeon Platinum 8100 Series
• Intel Xeon Platinum 8200 Series
IDEAL APPLICATIONS
• Enterprise Data Centers
• Server Repair and Replacement
• Cloud Infrastructure
• VMware Virtualization
• Microsoft Hyper-V Environments
• SQL Database Servers
• Software Defined Storage
• Virtual Desktop Infrastructure (VDI)
• High Availability Clusters
• Mission-Critical Business Applications
PACKAGE INCLUDES
• Dell EMC PowerEdge R640 Motherboard
• Dell Part Number: RGP26
• Dell DP/N: 0RGP26
IMPORTANT COMPATIBILITY NOTICE
This motherboard is designed specifically for Dell EMC PowerEdge R640 rack servers. Please verify compatibility using your service tag, processor generation, memory configuration, BIOS revision, and installed hardware before purchasing.
Processors, heatsinks, memory modules, RAID controllers, riser cards, network daughter cards, drives, cables, and other accessories are not included.
Functional Equivalent part numbers: G5DR5 / 0G5DR5, CRT1G / 0CRT1G, X45NX / 0X45NX, HG0J8 / 0HG0J8, XFK4K / 0XFK4K, 8HT8T / 08HT8T, 6DKY5 / 06DKY5, W23H8 / 0W23H8, PHYDR / 0PHYDR, 6NR82 / 06NR82, RGP26 / 0RGP26, 08R9M / 008R9M, H28RR / 0H28RR, P2YGM / 0P2YGM, RJCR7 / 0RJCR7, 413MP / 0413MP, 7F8T0 / 07F8T0, JXP9N / 0JXP9N, GRR79 / 0GRR79
