Intel 128GB 1Rx4 PC4-21300 DDR4-2666 Optane DC Persistent Memory NMA1XXD128GPS

Intel Optane DC Persistent Memory 128GB DDR4 2666MHz ECC Registered DIMM NMA1XXD128GPS

The Intel Optane DC Persistent Memory 100 Series (NMA1XXD128GPS) is a 128GB enterprise-class memory module designed to bridge the gap between traditional DRAM and high-capacity storage. Built on Intel’s Optane technology (Apache Pass), this module delivers a unique combination of large memory capacity, persistence, and high throughput, making it ideal for data-intensive applications and modern server environments.

Unlike standard memory, Optane Persistent Memory can operate in multiple modes, enabling systems to scale memory capacity dramatically while maintaining low latency access and data persistence.

NOTE: It is not standard RAM; it is a smart 'turbocharger' for your storage that learns which apps you use most so they load almost instantly."

• 128GB capacity persistent memory module

• DDR4 2666MHz (PC4-21300) interface

• Persistent + volatile memory functionality

• Registered ECC for enterprise reliability

• AES 256-bit hardware encryption

• Optimized for Intel Xeon Scalable (Cascade Lake)

• Supports Memory Mode & App Direct Mode

• Capacity: 128GB

• Memory Type: DDR4 SDRAM with Persistent Memory

• Interface: DDR-T (288-pin DIMM)

• Speed: 2666 MHz

• CAS Latency: CL19

• Rank: 1Rx4 (Single Rank x4)

• Voltage: 1.2V

• Error Correction: ECC Registered

• Max TDP: 15W

• Read Bandwidth: Up to 6.8 GB/s

• Write Bandwidth: Up to 1.85 GB/s

• Endurance:

  • Up to 292 PBW (256B workload)

  • Up to 91 PBW (64B workload)

• MTBF: 2,000,000 hours

• Operating Temperature: 1°C to 85°C

This module provides high endurance and consistent performance, ideal for memory-intensive enterprise workloads.

Persistent Memory Modes

• Memory Mode:

  • Acts as volatile system memory

  • DRAM used as cache

  • Enables massive memory expansion at lower cost

• App Direct Mode:

  • Provides byte-addressable persistent storage

  • Data remains intact after power loss

  • Ideal for databases, analytics, and in-memory computing

Data Protection & Security

• AES 256-bit hardware encryption

• Power-loss data protection

• End-to-end data integrity protection

This module is exclusively compatible with 2nd Generation Intel Xeon Scalable processors (Cascade Lake):

• Xeon Platinum 8200 Series

• Xeon Gold 6200 Series

• Xeon Gold 5200 Series

• Xeon Silver 4215 / 4215R

Important:

• ❌ Not compatible with 1st Gen Xeon (Skylake)

• ❌ Not compatible with 3rd Gen Xeon (Ice Lake)

• Chipset: Intel C620 Series (C621 / C622)

• Motherboards: Optane-enabled server boards only

• BIOS: Requires updated firmware (typically v3.0a or newer)

Supermicro X11 Series

• X11SPL-F

• X11SPM-TPF / X11SPM-F

• X11DPi-N / X11DPi-NT

• X11DAC

Intel Server Boards

• S2600WF Family

• S2600BP Family

Tyan Tempest Series

• Tempest CX S7106

• Tempest HX S7100

• Dell PowerEdge: R640, R740, R740xd, R840, R940

• HPE ProLiant: DL360 Gen10, DL380 Gen10

• Lenovo ThinkSystem: SR630, SR650, SR850, SR950

• Gigabyte Servers: Most dual-socket systems (post-2019)

• Must be paired with standard DDR4 RDIMM or LRDIMM memory

• Cannot operate as a standalone memory module

• Requires specific DIMM slot population rules per motherboard

• Some configurations require minimum CPU core counts

The Intel Optane DC Persistent Memory 128GB (NMA1XXD128GPS) is a powerful solution for organizations seeking to expand memory capacity, improve application performance, and enable persistent data workloads, making it ideal for databases, virtualization, AI, and real-time analytics environments.
