Micron 3.84TB NVMe U.2 PCIe Gen 3.0 x4 RI 2.5" SSD 9300 Pro Series MTFDHAL3T8TDP for Supermicro Server

Part Numbers: MTFDHAL3T8TDP | MTFDHAL3T8TDP-1AT1ZABYY | MTFDHAL3T8TDP-1AT1Z

Overview

The Micron 9300 Pro 3.84TB NVMe SSD is an enterprise-grade, read‑intensive storage solution built for high-performance data center environments. Engineered to accelerate demanding workloads such as AI/ML, caching, NoSQL databases, and OLTP applications, it delivers exceptional speed, low latency, and robust data protection.

Key Features

• Enterprise-class NVMe SSD optimized for read-intensive workloads
• High capacity storage designed for cloud and hyperscale deployments
• PCIe Gen3 x4 interface for fast data throughput
• Advanced 3D TLC NAND technology for endurance and efficiency
• Built-in enterprise security and reliability features

Core Architecture

• Capacity: 3.84TB (unformatted, 1TB = 1 trillion bytes)
• Form Factor: 2.5-inch Small Form Factor (15mm thickness)
• Interface: PCIe Gen3 x4
• Protocol: NVMe 1.2
• Connector: U.2 (SFF-8639)
• NAND Flash: Micron 64-layer 3D TLC NAND
• Controller: Microchip Belmar (PM8607)

Performance (Steady State)

• Sequential Read Speed: Up to 3,500 MB/s
• Sequential Write Speed: 3,100 MB/s to 3,500 MB/s
• Random Read (4KB): Up to 850,000 IOPS
• Random Write (4KB): Up to 145,000 IOPS
• Average Latency:
  • Read: 86 µs
  • Write: 11 µs

Reliability & Endurance

• Endurance Rating: 16,800 TBW
• Drive Writes Per Day: Approximately 1 DWPD (over 5 years)
• MTBF: 2,000,000 hours
• UBER: Less than 1 sector per 10¹⁷ bits read

Power & Environmental

• Power Supply:
  • 12V main supply (±8%)
  • 3.3V auxiliary SMBus (±8%)
• Power Consumption:
  • Sequential Read: Up to 14W
  • Sequential Write: Up to 21W
  • Idle: 6.5W
• Operating Temperature: 0°C to 70°C
• Non-Operating Shock: 1000G @ 0.5ms
• Non-Operating Vibration: 3.1 GRMS (5–800Hz)

Enterprise Features

• Power Loss Protection (PLP): Protects data-in-flight and data-at-rest
• Multi-Tenancy Support: Up to 32 NVMe namespaces
• Flex Capacity: Adjustable capacity for increased endurance and performance
• Data Path Protection: End-to-end protection for user data and metadata
• Security: Digitally signed firmware and crypto erase capability
• Management: Compatible with Micron Storage Executive tools

Physical Specifications

• Height: 15.00 mm
• Width: 70.10 mm
• Length: 100.45 mm
• Weight: Less than 235 grams

Ideal Applications

• Cloud and hyperscale data centers
• Artificial intelligence and machine learning workloads
• Caching and real-time analytics systems
• NoSQL and large-scale database environments
• Enterprise storage and virtualization platforms

The Micron 9300 Pro 3.84TB NVMe SSD delivers a powerful combination of performance, endurance, and enterprise-grade features, making it a reliable choice for modern, data-intensive infrastructures.
